Custom Cut Paint Mask Stencil

Stencil Films for Airbrush Masking.
Make a design on-line or upload one from your pc. We will have a plotter cut it out the design on painter masking sheets. Put the Stencil on a canvas and spray paint over it and then peel it off and have your design on the canvas. Spray Mask Stencil Films are 3 mil films with a low-tack adhesive used for stencil applications, especially for paint and spray applications, vehicle lettering, promotional lettering and signs in general. Stencil Film is a transparent grey film designed for use on flexible, uneven surfaces.

Custom Cut Airbrush Vinyl Stencil

Custom Cut Spray Mask Stencil

Upload File To Make Stencil

Electrochemical Etching Stencil Designer
This transparent blue PVC film has been formulated for stencil applications, especially spray and paint techniques. ORACAL 813 features a low-tack, water-based adhesive. It is ideal for water-based paint applications; smooth, flat, rigid substrates and surfaces; large area capabilities; and applications requiring background visibility.

Vinyl Information

SKU:  ORS813
Adhesive Water-based polyacrylate, low-tack and removable
Adhesive Power (FINAT FTM-1, after 24 h, stainless steel) 1.37 lb/in
Areas of Use Water-based paint applications; smooth, flat, rigid substrates and surfaces; large area capabilities
Color Blue
Dimensional Stability Adhered to steel, no measurable shrinkage in cross direction; in length, < .016"
Elongation at Break (across) (DIN EN ISO 527) across: min.90%
Elongation at Break (along) (DIN EN ISO 527) along: min. 90%
Minimum application temperature 50°F
Release Paper 84# silicone-coated paper with excellent weeding and release characteristics.
Seawaterability Not applicable
Shelf Life (68 °F/50% relative humidity) 2 years
Temperature Resistance Not applicable
Tensile Strength (across) (DIN EN ISO 527) across min. 19MPa
Tensile Strength (along) (DIN EN ISO 527) along: 19 MPa
Thickness 3 mil
The compatibility of selected lacquers and paints should be tested by the user, prior to application of the material.

Surfaces to which the material will be applied must be thoroughly cleaned from dust, grease or any contamination which could affect the adhesion of the material. Freshly lacquered or painted surfaces should be completely cured. Films with structured surface are naturally more sensitive than the unstructured. Accordingly, these films are to be treated carefully both in processing and in cleaning. Impurities affect the appearance of structured films and require more frequent cleaning. Furthermore the application information published by ORAFOL is to be considered. The batch traceability according to ISO 9001 is possible on the basis of the roll number.

All ORAMASKŪ products are subject to careful quality control throughout the manufacturing process and are warranted to be of merchantable quality and free from manufacturing defects. Published information concerning ORAMASKŪ products is based upon research which the Company believes to be reliable although such information does not constitute a warranty. Because of the variety of uses of ORAMASKŪ products and the continuing development of new applications, the purchaser should carefully consider the suitability and performance of the product for each intended use, and the purchaser shall assume all risks regarding such use. All specifications are subject to change without prior notice. WARNING: This product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
